Rails
Description
Lightweight anodized aluminum rails for smooth and frictionless seat travel. Available in standard and extended lengths.
Order Reference
| Ref | Code | Description | |
|---|---|---|---|
| 1 | 101016 | Rail without plastic bottom part, 850mm per piece | Add to Quote |
| 2.1 | 101018 | Stop end cap for rail (Small) | Add to Quote |
| 2.2 | 101019 | Stop end cap for rail (Big) | Add to Quote |
| 3.1 | 101022 | Rail plastic bottom part, 750mm x 2.2mm | Add to Quote |
| 3.2 | 101023-1 | (Thin) Rail plastic bottom part, 390mm | Add to Quote |
| 3.2 | 101023-2 | (Thick) Rail plastic bottom part, 390mm | Add to Quote |
| 4.1 | 106010 | Small square head bolt for rail fixing M5x25, for 1x | Add to Quote |
| 4.2 | 106029 | Small square head bolt for rail fixing M6x40mm, for 2x, 4x & 8+ | Add to Quote |
| 5.1 | 101017 | Rubber Washer Ø5 | Add to Quote |
| 5.2 | 101024 | Screw Holder 12mm for (Thick) Rail plastic bottom part 390mm | Add to Quote |
| 5.2 | 101025 | Screw Holder 21mm for (Thin) Rail plastic bottom part | Add to Quote |
| 6.1 | 106018 | Flat Washer M5 | Add to Quote |
| 6.2 | 106035 | Flat Washer M6 | Add to Quote |
| 7.1 | 106017 | Spring Washer M5 | Add to Quote |
| 7.2 | 106034 | Spring Washer M6 | Add to Quote |
| 8.1 | 106016 | Wing nut M5 | Add to Quote |
| 8.2 | 106032 | Wing nut M6 | Add to Quote |
| 9 | 106003 | Self-tapping cross-head screw M4x6mm | Add to Quote |
Need the Rails?
Contact our team for pricing, availability and bulk orders.
